Fluid Bed Dryer TG 200

Fluid Bed Dryer TG 200

Fluid Bed Dryer TG 200 incl. clamping lid “comfort” with filter bag
(please order drying container separately)

70.760.0001

TG 200

200–240 V, 50/60 Hz

Drying container TG 200

Selection help

The fluid bed dryer TG 200 can be equipped with a variety of containers and covers.

The 6 l drying container of glass or stainless steel is used for drying large sample amounts. The glass container allows visual control of the dispersion degree of the sample, during the drying process. Thus, the operator can directly adjust the air flow if necessary.

The glass drying container with 3 x 0.3 l volume is equipped with 3 removable glasses. It permits the simultaneous drying of three samples, also of different materials, under the same conditions. This helps to avoid cross contamination.

Container lids with filter fleece inserts are available as optional accessories for both containers. These can be easily exchanged after each drying process to avoid cross contamination. The filter fleece is mainly used for samples with a particle size below 100 μm. It allows for sample recovery with minimal loss.

Please note: The TG 200 is only suitable for drying samples with a particle size >63 µm.

72.783.0001

Drying container of glass, 6 litres

72.783.0002

Drying container of stainless steel, 6 litres

Accessories TG 200

72.643.0001

Clamping lid “comfort” with filter insert (exchangeable), incl. 10 replacement filters

72.143.0001

Filter insert for clamping lid “comfort”, 10 pieces

72.107.0002

Clamping lid “comfort” with filter bag

02.186.0015

Filter bag for clamping lid “comfort”

72.107.0001

Lid with filter insert for 0.3 litres drying containers, 3 pieces

03.186.0024

Filter insert for 0.3 litres drying container, 1 piece

02.045.0020

Spare drying container of glass, 0.3 litres, 1 piece

02.186.0004

Filter bag for drying container 0.3 litres, 1 piece

72.001.0005

Adapter for drying sieves 203 mm Ø

72.143.0003

Dust filter for TG 200, 10 pcs.

72.737.0003

Quick-clamping elements for TG 200, 1 pair
