Sieve Shakers

RETSCH’s line of sieving machines not only covers a wide measuring range. Thanks to various sieving motions and sieve sizes it is possible to select the ideal instrument for practically any bulk material. The instruments produce exact and reproducible results and comply with the requirements for the test materials monitoring according to DIN EN ISO 9000 ff.

Vibratory Sieve Shaker AS 200 basic		Vibratory Sieve Shaker AS 200 digit

Measuring range*: 20 µm - 25 mm Sieving motion: throwing motion with angular momentum Amplitude: analog, 0 - 3 mm Time display: analog, 1 - 60 min Suitable sieve diameters: 100 mm / 150 mm / 200 mm / 203 mm (8")		Measuring range*: 20 µm - 25 mm Sieving motion: throwing motion with angular momentum Amplitude: analog, 0 - 3 mm Time display: digital, 1 - 99 min Suitable sieve diameters: 100 mm / 150 mm / 200 mm / 203 mm (8")

Vibratory Sieve Shaker AS 200 control		Vibratory Sieve Shaker AS 300 control

Measuring range*: 20 µm - 25 mm Sieving motion: throwing motion with angular momentum Amplitude: digital, 0.2 - 3 mm Time display: digital, 1 - 99 min Suitable sieve diameters: 100 mm / 150 mm / 200 mm / 203 mm (8")		Measuring range*: 20 µm - 40 mm Sieving motion: throwing motion with angular momentum Amplitude: digital, 0.2 - > 2 mm Time display: digital, 1 - 99 min Suitable sieve diameters: &100 mm / 150 mm / 200 mm / 203 mm (8") / 305 mm / 315 mm

Vibratory Sieve Shaker AS 450 basic		Vibratory Sieve Shaker AS 450 control

Measuring range*: 25 µm - 125 mm Sieving motion: throwing motion with angular momentum - 3D movement Amplitude: digital, 0 - > 2 mm Suitable sieve diameters: 400 mm / 450 mm		Measuring range*: 25 µm - 125 mm Sieving motion: throwing motion with angular momentum - 3D movement Amplitude: digital, 0.2 - > 2.2 mm Suitable sieve diameters: 400 mm / 450 mm

Air Jet Sieving Machine AS 200 jet		Horizontal Sieve Shaker AS 400 control

Measuring range*: 10 µm - ~ 4 mm Sieving motion: dispersion by air jet Speed: digital, 5 - 55 min^-1 (nozzle)		Measuring range*: 45 µm - 63 mm Sieving motion: horizontal circular motion Suitable sieve diameters: 100 mm / 150 mm / 200 mm / 203 mm (8") / 305 mm / 315 mm / 400 mm

Tap Sieve Shaker AS 200 tap

Measuring range*: 20 µm - 25 mm Sieving motion: horizontal circular motion with taps Suitable sieve diameters: 200 mm / 203 mm (8")
